NAME

PARAMETERS

NOTES

Transfer speed

27M/MIN

Blade speed

6272rpm/min

Blade diameter

φ305mm

Production

 500pcs/hour

Working material

Plywood （thickness）≤18mm
Partical board (thickness)≤18mm

Plywood size

1220*2440*18mm

Motor power

7.5KW

Total power

42.42KW

Loading(max)

1800MM

Loading working stroke(max)

150mm

Unloading working stroke(max)

2000mm

Table lifter Load weight (front)

15mm=80pcs  80pcs*26kg=2T

Table lifter Load weight (back)

2T
